Description

Description

Three-pole (3P) circuit breaker is a reliable protection device for electrical installations in three-phase systems. It protects against overloads and short circuits, ensuring safety in industrial, commercial, and residential installations.

Application:
Recommended for protecting power supply systems for industrial equipment and technical systems in commercial buildings.

Technical Specifications:

  • Number of poles: 3
  • Tripping characteristic: C
  • Rated current: 32A
  • Protection class: IP20
  • Max. conductor cross-section: 1 to 25 mm²
  • Max. tightening torque: 2.5 Nm
  • Mounting: standard DIN rail TH35 mm
  • Operating temperature: -30°C to 60°C
  • Rated operating voltage: AC 230 / 400V
  • Breaking capacity: 6 kA
  • Electrical lifespan: 5000 cycles
  • Mechanical lifespan: 20000 cycles
  • CE certified

Circuit breaker installation fuse ESKA 32A 3P C32

Product form

Free pickup in our shop(s)

Barcode: 8699430561407

36,00 zł (netto: 29,27 zł)

Large quantity

    • Shipped today? Order within:
      00day
      08hours
      04minutes
      57seconds

    Icon for shopping_bagBuy as a set

    Description

    Description

    Three-pole (3P) circuit breaker is a reliable protection device for electrical installations in three-phase systems. It protects against overloads and short circuits, ensuring safety in industrial, commercial, and residential installations.

    Application:
    Recommended for protecting power supply systems for industrial equipment and technical systems in commercial buildings.

    Technical Specifications:

    • Number of poles: 3
    • Tripping characteristic: C
    • Rated current: 32A
    • Protection class: IP20
    • Max. conductor cross-section: 1 to 25 mm²
    • Max. tightening torque: 2.5 Nm
    • Mounting: standard DIN rail TH35 mm
    • Operating temperature: -30°C to 60°C
    • Rated operating voltage: AC 230 / 400V
    • Breaking capacity: 6 kA
    • Electrical lifespan: 5000 cycles
    • Mechanical lifespan: 20000 cycles
    • CE certified
